Imported Fully Automatic Box Stitching Machine
Auto Stitcher now invented with Auto-Feeding system to reduce manual labor and achieve higher production.
Capability and Features
- Auto feed, auto fold and auto stacker delivery with counter
- Four servo motor drive imported from TAIWAN DELTA, Accurate precision, reduce the mechanical transmission parts, can effectively reduce the mechanical failure rate
- The whole control system adopts Delta PLC control system
- Control the contactor in the cabinet are all of Germany’s Siemens brand
- Relays, circuit breaker adopts French Schneider brand, photoelectric and proximity switch adopts Autonics Korea brand
- Bottom die , blade adopt Japan’s tungsten steel production (wear)
- The whole stitch head adopt specifical tungsten, CNC precision machining
- Change carton size and adjust carton nail distance only take one minute can be completed, greatly save time it is easy to operate
- Can nail box & has a lid without cover carton box (with and without cover is required at time of order to nail in mechanical specification)
- After a period of automatic counting function, completes the product number can be set according to the number (1-99) fold, to the end of the conveying machinery, convenient packing banding.
- Machine : 600 nail/min
- Nail distance: 30-120 mm Arbitrary adjustable
- A dual purpose, i can stitch single piece and double piece, and irregular carton
- Size adopt full computerized control, change size only take 2-3 mins
- Can stitch strengthen nail, single nail , double nail, once complete
- Feed automatic counting, finished product is sent out banding
- Suitable for small and medium carton, binding quickly and save labor, there is no limit to the technology
- Adjustment nail distance , use computer set up , adjust nail distance automatically, nail distance 30-120 mm arbitrary adjustable
- The machine adopts computer screen display failure
- The bottom without cover carton also can nail (special)
- Used three layer, five layer corrugated cardboard, seven layers (seven layers need special instructions)
- The machine adopt four servo motors( two motor for stitch head , another two for nail distance motor)
